JWBS-18-T JET Wood Bandsaw

  • Wheel diameter 470mm
  • Max. height/-resaw cap. 406/457mm
  • Table size 692×508×41mm

£2,657.00Excl. VAT + Delivery

SKU 1b5972786dfa Categories , Tag Brand:

Description

Features

The powerful 3.7kW (5hp) motor provides reserves for difficult crosscuts and in continuous operation
Precision-planed cast iron table for added stability and workpiece support
Saw blade quick release and tensioning system
Two cutting speeds (640, 1’200m/min) for working efficiently with hard and soft woods
Electro-mechanical motor brake
Tool-free, independently adjustable ball bearing guide system for quick and easy adjustments and smooth operation
Sturdy parallel fence with integrated fine-tuning, operated on a round rod
Heavy-duty guide post adjusted via a toothed rack and handwheel for optimal saw blade support
Solid construction, stable and torsionally rigid

Specifications

  • Motor (V/kW) 400/1.5
  • Wheel diameter (mm) 470
  • Max. cutting height/-resaw capacity (mm) 406/457
  • Table tilt 5° left, 45° right
  • Table size (mm) 692 x 508 x 41
  • Blade speed (m/min) 570/900
  • Saw blade (mm) 3’810
  • Saw blade width min/max. (mm) 3/32
  • Blade guide – Ball bearing
  • Table height from floor (mm) 940
  • Miter t-slot (mm) 19.1 x 9.5
  • Dimensions (mm) 914 x 864 x 2’032
  • Weight (kg) 217
  • Dust port (mm) 100
