Baileigh WJT-3939 Welding Jig Table

  • 990mm x 990mm welding jig table
  • Made from Q345 Steel
  • Brinell Hardness 140-160
  • 2 ton weight capacity

£1,452.75Excl. VAT + Delivery

SKU 2006658 Categories , , Tag Brand:

Description

The WJT-3939 welding jig table is perfect for thos small shops looking for a good economical fixture mounting system. It ffeatures one solid mounting surface that has a flatness of /- .0025″ and a Brinell hardness rating of between 140 and 160.

The best thing about the WJT-3939 metal welding table is that it accepts all of the same fixtures that the Baileigh heavy duty tables use, so when the time is right and the shop grows, you can step right up without having the large expense of swapping out fixtures.

39” x 39” metal welding table
Made from Q345 Steel
Brinell Hardness 140~160
Single Mounting Surface
Expandable
2 ton weight capacity
Industry Standard 28mm Mounting holes
100mm hole spacing
Etched Position Marks
Includes table Oiler, Brush and cleaning stone

Specifications

Item Number WJT-3939
Working Table Size 39″ x 39″
Table Load Capacity 2 Tons
Table Height 33.5″
Shipping Weight 1,540 lbs
Table Flatness +/- .0025″
Number of Mounting Surfaces 1
Mounting Hole Size 28mm
Mounting Hole Spacing 100mm

* specifications subject to change without notice.
