MDA-35Q Magnetic Drill

Specifications

• Magnetic Drilling Machine
• MDA-35Q input 1.100 Watt
• On-load speed 450 rpm
• Tool holder 19 mm Weldon
• Quick-release chuck
• Coolant supply internal
• Voltage230 V 50/60 Hz
• Magnetic adhesion: 9,000N Tool force (on 10 mm steel):2.100N
• Cutting Ø max. in steel- core cutters: 12 – 35mm- Twist drills: 1 – 13 mm with Weldon drill chuck
• Counter boring Ø10 – 40 mm
• Cutting depth 50 mm
• Stroke 120 mm
• Size of magnetic base70 x 185 mm
• Min. material thickness 6 mm
• Weight 11.5 kg
• Noise emission 92 dB(A) @ 300 mm distance from the motor
• Vibration on the handle AC=3,5 mm/s² and VC=3,2 mm/s
