Promac PBM-1839BDV Vertical Mill Drill

  • 230v Single phase 0,75kw motor
  • Cutting capacity for steel 20mm
  • Speed range 100-2,000rpm
  • Table Dimensions 700 x 160mm

£2,890.00Excl. VAT + Delivery

SKU a7d3287b20bd Category Tag Brand:

Description

ƒ Powerful, smooth, brushless DC motor with variable speed control ƒ Digital display of the drilling or milling depth ƒ Electronically switchable thread cutting device ƒ Variable rotation speed of the spindle ƒ Large work table 700×160mm ƒ Chuck protection and emergency stop button ƒ Solid, vibration-damping cast iron case (GG-20) View Manuals

Specifications

  • Motor (V/kW) 230/0.75
  • Morse taper MT3
  • Cutting capacity for steel (ø-mm) 20
  • Spindle stroke (mm) 70
  • Max. milling plan/groove cutter (mm) 50/16
  • Speed range (min-1) 100–2’000 variable
  • X axis, longitudinal stroke (mm) 400
  • Y axis, transverse stroke (mm) 190
  • Z axis, vertical stroke (mm) 290
  • Tapping capacity max. M12
  • Spindle taper (mm) 370
  • Throat (mm) 190
  • Table dimensions (mm) 700×160
  • T-Slot width (mm) 12
  • Weight (kg) 110
